Bussmann FNA-2/10 - Midget Fast-Acting Fuse 2A@125V (10kA Interrupt Rating)

Bussmann FNA-2/10 is a midget fast-acting fuse designed for overcurrent protection in low-voltage circuits. Rated for 125V AC/DC systems with a 2A current capacity, it features a compact 1-1/2" length and 0.41" diameter ceramic body construction. Certified to UL-248-12, CSA Class 1422-01, and CE standards, this 10kA interrupting capacity fuse is commonly used in industrial control panels, instrumentation, and appliance protection circuits.

Key Features & Specifications

• Type: Fast-acting ceramic body fuse (FNA series)
• Voltage Rating: 125V AC/DC
• Current Rating: 2A
• Dimensions: 1-1/2" length x 0.41" diameter
• Standards: UL-248-12 (JDYX), CSA Class 1422-01, CE
• Applications: Control circuits, instrumentation, appliance protection
• Class Rating: Midget
• Barrels: 1
• AIC rating: 10kA@125V
• Weight: 1.1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712713375
• GTIN: 00051712713375
