Bussmann FNA-12 - Midget Fuse 12A (10kA@125V Interrupting Rating)

Bussmann FNA-12 is a low-voltage midget fuse designed for circuit protection in industrial electrical systems. This 12A current-rated fuse operates at 125V AC with an interrupting rating of 10kA, providing reliable overcurrent protection in demanding applications. The compact fuse features a 0.82-inch diameter cylindrical body measuring 1-1/2 inches in length with dual barrel construction and weighs 1.3 lb. It complies with CE, CSA Class 1422-01, and UL-248-12 Guide JDYX standards, ensuring industry-recognized safety and performance. Typical applications include protection of control circuits, transformers, and electrical equipment in industrial facilities and commercial installations.

Key Features & Specifications

• Type: Low-voltage midget fuse with dual barrel construction
• Voltage Rating: 125V AC
• Current Rating: 12A
• Dimensions: 1-1/2 inches length, 0.82 inches diameter
• Weight: 1.3 lb
• Standards: CE, CSA Class 1422-01, UL-248-12 Guide JDYX
• Applications: Industrial control circuits, transformers, electrical equipment protection
• Class Rating: Midget
• Barrels: 2
• AIC rating: 10kA@125V
• Family: FNA Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712713658
• GTIN: 00051712713658
