Littelfuse FLNR60ID - RK5 Time-Delay Fuse 60A@250V (200kA AIC)

Littelfuse FLNR60ID is a time-delay low-voltage fuse designed for circuit protection in industrial power distribution systems. This RK5-class fuse features a 250V AC rating with a 60A current capacity and 200kA interrupting rating, housed in a compact 0.81-inch diameter ferrule-rejection package for secure mounting. The TD (Time Delay) characteristic provides overload protection while withstanding temporary inrush currents, complying with industry standards for branch circuit protection. Typical applications include motor control centers, transformers, and power distribution panels where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: FLNR time-delay fuse with ferrule rejection
• Voltage Rating: 250V AC
• Current Rating: 60A
• Dimensions: 0.81" diameter
• Standards: RK5 class rating
• Applications: Industrial power distribution, motor protection
• AIC rating: 200kA@250V
• Connection: Ferrule rejection
• Velocity: Time Delay (TD)
• Barrels: 1

Product Identification

• UPC: 079458023848
• GTIN: 00079458023848
