Littelfuse FLM-010 - Low Voltage Fuse 10A 125V (5x20mm Fast-Acting Glass Tube)

Littelfuse FLM-010 is a low-voltage fuse designed for circuit protection in industrial and commercial applications. It features a 10A current rating and 125V AC/DC voltage rating, housed in a compact 5x20mm glass tube construction with nickel-plated end caps for reliable conductivity. The fuse meets UL 248-14 standards and is rated for 35A interrupting capacity, ensuring compliance with safety requirements. Typical applications include protection of control circuits, instrumentation, and small power supplies where precise overcurrent protection is critical.

Key Features & Specifications

• Type: Fast-acting glass tube fuse with nickel-plated end caps
• Voltage Rating: 125V AC/DC
• Current Rating: 10A
• Dimensions: 5mm diameter x 20mm length
• Standards: UL 248-14 recognized
• Applications: Control circuits, instrumentation, power supplies
• Interrupting Rating: 35A
• Operating Temperature: -55°C to +125°C
• Construction: Glass body with nickel-plated brass end caps

Product Identification

• UPC: 079458140651
• GTIN: 00079458140651
