Littelfuse FLA5 - Midget Fast-Acting Fuse 5A@125V (10kA AIC)

Littelfuse FLA5 is a midget fast-acting fuse designed for overcurrent protection in low-voltage circuits. It features a 125V AC/DC voltage rating and 5A current rating with a 10kA interrupting capacity at 125V, housed in a compact 0.41" diameter single-barrel ceramic body. The FLA Series fuse meets industry standards for circuit protection with its fast-acting characteristics and midget class rating. Typical applications include protection of control circuits, transformers, and small motors in industrial equipment.

Key Features & Specifications

• Type: Fast-acting ceramic body fuse (FLA Series)
• Voltage Rating: 125V AC/DC
• Current Rating: 5A
• Diameter: 0.41" (10.4mm)
• Class Rating: Midget
• AIC Rating: 10kA@125V
• Barrels: 1
• Standards: UL/CSA recognized
• Applications: Control circuits, transformers, small motor protection
