Square D FHL36025 - Molded Case Circuit Breaker, 25A 600V 3P
Square D FHL36025 - Molded Case Circuit Breaker, 25A 600V 3P

Square D FHL36025 - Molded Case Circuit Breaker, 25A 600V 3P

Square D
Price
Save $2,069.30
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FHL36025 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 25A current rating and a 600V voltage rating, housed within a compact F-frame measuring 162.6 mm H x 114.3 mm W x 104.9 mm D and weighing 4.817 lb. The breaker is UL Listed and CSA Certified, ensuring compliance with North American safety standards for its thermal-magnetic protection with long-time and instantaneous (LI) trip functions. Its 25kA interrupting rating at 480V and feed-thru connection make it suitable for protecting feeders and branch circuits in industrial control panels and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, FHL Series, Thermal-Magnetic Protection with Long-Time and Instantaneous (LI) Trip
  • Voltage Rating: 600V AC
  • Current Rating: 25A
  • Dimensions: 6.4 in (162.6 mm) H x 4.5 in (114.3 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL Listed, CSA Certified
  • Applications: Industrial power distribution, feeder and branch circuit protection, motor control centers
  • Phase: 3
  • AIC Rating: 25kA @ 480V
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: F Frame
  • Weight: 4.817 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901563358
  • GTIN: 00785901563358
