Square D FH36090 - Molded Case Circuit Breaker 90A 600V 3-Pole
Square D FH36090 - Molded Case Circuit Breaker 90A 600V 3-Pole

Square D FH36090 - Molded Case Circuit Breaker 90A 600V 3-Pole

Square D
Price
Save $-344.22
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FH36090 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 90A current rating and a 600V voltage rating, housed within a compact F-frame construction measuring 162.6 mm H x 114.3 mm W x 104.9 mm D and weighing 6 lb. The breaker complies with industry standards for thermal-magnetic protection, offering a 25kA interrupting capacity at 480V and an operational temperature range of -25 to 70 °C. Its I-Line plug-in connection facilitates efficient installation in panelboards for applications such as motor control centers and feeder circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, I-Line Style Plug-In
  • Voltage Rating: 600V AC
  • Current Rating: 90A
  • Dimensions: 162.6 mm H x 114.3 mm W x 104.9 mm D (6.4 in x 4.5 in x 4.13 in)
  • Standards: Industry Standard Thermal-Magnetic Trip
  • Applications: Industrial Power Distribution, Motor Control Centers, Feeder Protection
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 3
  • AIC Rating: 25kA @ 480V
  • Connection: Plug-In
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI) Trip
  • Frame Size: F Frame
  • Family: I-Line
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901241393
  • GTIN: 00785901241393
