Square D FH36015 - Molded Case Circuit Breaker 15A 600V 3P
Square D FH36015 - Molded Case Circuit Breaker 15A 600V 3P

Square D FH36015 - Molded Case Circuit Breaker 15A 600V 3P

Square D
Price
Save $230.40
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Square D FH36015 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 15A current rating and a 600V voltage rating, housed in a compact F-frame design with dimensions of 162.6 mm H x 114.3 mm W x 104.9 mm D and a weight of 6 lb. This thermal magnetic breaker complies with industry standards for its 25kA interrupting capacity at 480V and operates reliably across a temperature range of -25 to 70 °C. Its I-Line style plug-in connection facilitates installation in panelboards for typical applications like motor control centers, HVAC systems, and industrial machinery protection.

Key Features & Specifications
  • Type: FH Series, Molded Case, Thermal Magnetic Protection with Long-Time and Instantaneous (LI) Trip Functions
  • Voltage Rating: 600V AC
  • Current Rating: 15A
  • Dimensions: 162.6 mm H x 114.3 mm W x 104.9 mm D (6.4 in x 4.5 in x 4.13 in)
  • Standards: Designed to meet applicable industry standards for circuit protection
  • Applications: Industrial power distribution, motor control centers, HVAC systems, machinery protection
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 3
  • AIC Rating: 25kA at 480V
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: F Frame
  • Weight: 6 lb


Product Identification
  • UPC: 785901241324
  • GTIN: 00785901241324
