Square D FH26060BC - Molded Case Breaker 60A 600V 2-Pole
Square D FH26060BC - Molded Case Breaker 60A 600V 2-Pole

Square D FH26060BC - Molded Case Breaker 60A 600V 2-Pole

Square D
Price
Save $-396.88
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D FH26060BC is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 60A current rating and a 600V voltage rating, suitable for single-phase applications. The breaker is constructed with a compact F-frame design, measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 6 lb, and utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection. It complies with major international standards including UL, CSA, NOM, IEC, CCC, and CE, ensuring broad acceptance. Typical applications include protection of feeders and branch circuits in panelboards and switchboards, compatible with 14 to 1/0 AWG aluminum or copper conductors.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, I-Line Family, FH Type
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 6.4 in (162.6 mm) H x 3 in (76.2 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL, CSA, NOM, IEC, CCC, CE Certified
  • Applications: Industrial and Commercial Feeder/Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • Amperage: 60A
  • AIC rating: 25kA @ 480V
  • Connection: I-Line Style Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Wire Size: 14 to 1/0 AWG AL/CU
  • Certification: UL, CSA, NOM, IEC, CCC, CE
  • Country of Origin: Mexico
  • Weight: 6 lb


Product Identification
  • UPC: 785901343301
  • GTIN: 00785901343301
