Square D FH26060AC - 60A Molded Case Circuit Breaker (600V, 25kA AIC)
Square D FH26060AC - 60A Molded Case Circuit Breaker (600V, 25kA AIC)

Square D FH26060AC - 60A Molded Case Circuit Breaker (600V, 25kA AIC)

Square D
Price
Save $0
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D FH26060AC is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial electrical systems. It features a 60A current rating and a 600V AC voltage rating, housed within a compact F-frame measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 6 lb. This two-pole, single-phase unit utilizes a thermal-magnetic trip mechanism for long-time and instantaneous (LI) protection, achieving an interrupting capacity of 25kA at 480V AC. It is certified to UL, CSA, NOM, IEC, CCC, and CE standards for global compliance and is engineered for plug-in connection to I-Line panelboards in commercial and industrial power distribution applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip, I-Line Style Plug-In Connection
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 6.4 in (162.6 mm) H x 3 in (76.2 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL, CSA, NOM, IEC, CCC, CE
  • Applications: Industrial and Commercial Power Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Phase: 1
  • Amperage: 60A
  • AIC rating: 25kA@480V
  • Connection: I-Line Style Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: F Frame
  • Trip Type: Thermal-Magnetic
  • Breaker Type: Molded Case
  • Certification: UL, CSA, NOM, IEC, CCC, CE
  • Family: I-Line
  • Country of Origin: Mexico
  • Weight: 6 lb


Product Identification
  • UPC: 785901254782
  • GTIN: 00785901254782
