Square D FH26025AC - Molded Case Circuit Breaker, 25A 600V 2-Pole
Square D FH26025AC - Molded Case Circuit Breaker, 25A 600V 2-Pole

Square D FH26025AC - Molded Case Circuit Breaker, 25A 600V 2-Pole

Square D
Price
Save $-890.80
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FH26025AC is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 25A current rating and a 600V voltage rating, housed within a compact F-frame measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 6 lb. This thermal magnetic breaker offers long-time and instantaneous trip functions, is constructed for a wide operating temperature range of -25 to 70 °C, and complies with UL, CSA, NOM, IEC, CCC, and CE standards. Its typical applications include protecting branch circuits and equipment in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic Protection with Long Time and Instantaneous Trip Functions
  • Voltage Rating: 600V AC
  • Current Rating: 25A
  • Dimensions: 162.6 mm H x 76.2 mm W x 104.9 mm D (6.4 in x 3 in x 4.13 in)
  • Standards: UL, CSA, NOM, IEC, CCC, CE
  • Applications: Industrial and Commercial Panelboards/Switchboards
  • Switch Type: Circuit Breaker
  • Configuration: I-Line Style Plug-In
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC rating: 25kA @ 480V
  • Connection: I-Line Style Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Wire Size: 14 to 4 AWG AL/CU
  • Certification: UL, CSA, NOM, IEC, CCC, CE
  • Family: I-Line
  • Country of Origin: Mexico


Product Identification
  • GTIN: 00785901338086
