Square D FH16100A - Molded Case Circuit Breaker 100A 1P
Square D FH16100A - Molded Case Circuit Breaker 100A 1P

Square D FH16100A - Molded Case Circuit Breaker 100A 1P

Square D
Price
Save $-448.68
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FH16100A is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 100A current rating and a 277V voltage rating, suitable for single-phase applications. The breaker is constructed with a compact F-frame design, measuring 162.6 mm H x 38.1 mm W x 104.9 mm D and weighing 2 lb, and utilizes a thermal-magnetic trip unit for combined long-time and instantaneous protection functions. It complies with UL and CSA standards and offers a 25kA interrupting capacity at 240V. Typical applications include protection for feeders and branch circuits in panelboards and switchboards, compatible with copper conductors from AWG 14 to 1/0 and aluminum from AWG 12 to 1/0.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, I-Line Style Plug-In Connection
  • Voltage Rating: 277V AC
  • Current Rating: 100A
  • Dimensions: 6.4 in (162.6 mm) H x 1.5 in (38.1 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL, CSA
  • Applications: Industrial and Commercial Feeder/Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Single-Pole
  • Phase: 1
  • AIC Rating: 25kA @ 240V
  • Connection: Plug-In
  • Poles: 1
  • Protection: Thermal-Magnetic
  • Functions: Long Time and Instantaneous
  • Frame Size: F Frame
  • Wire Size: AWG 14 to 1/0 (Copper), AWG 12 to 1/0 (Aluminum)
  • Certification: UL, CSA
  • Family: I-Line
  • Country of Origin: Mexico
  • Weight: 2 lb


Product Identification
  • UPC: 785901338079
  • GTIN: 00785901338079
