Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)
Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)
Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)
Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)
Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)
Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)

Cutler Hammer FDC3080 - Molded Case Breaker 80A 600V 3P (100kA AIC)

Cutler Hammer
Price
Save $4,702.90
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDC3080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial electrical systems. It features a thermal-magnetic trip unit with long-time and instantaneous functions, rated for 80A continuous current and 600V maximum operating voltage. The breaker is constructed with a compact F-frame design measuring 3.38" x 6" x 4.13" (LxHxW) and a 4 lb bolt-on connection for secure panel mounting, operating within a temperature range of -25°C to 70°C (-13°F to 158°F). It is UL Listed and offers an interrupting capacity of 100kA at 480V AC, ensuring compliance with industry safety standards for demanding applications such as motor control centers, distribution panels, and industrial machinery.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Series C, FDC Type, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 80A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed
  • Applications: Industrial three-phase power distribution, motor protection, panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC Rating: 100kA @ 480V AC
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal-Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Weight: 4 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679451564
  • GTIN: 00786679451564
