Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P
Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P
Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P
Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P
Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P
Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P

Cutler Hammer FDC3035 - Molded Case Circuit Breaker 35A 600V 3P

Cutler Hammer
Price
Save $3,888.93
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDC3035 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial electrical systems. It features a 35A current rating and a 600V AC voltage rating, housed within a compact F-frame design measuring 3.38 in (D) x 6 in (H) x 4.13 in (W) and weighing 4.5 lb. This thermal-magnetic trip unit provides both long-time and instantaneous trip functions, is UL Listed, and operates effectively across a temperature range of -25°C to 70°C (-13°F to 158°F). Its 100kA interrupting rating at 480V AC makes it suitable for protecting feeders, motors, and branch circuits in commercial and industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed
  • Applications: Industrial Feeder and Branch Circuit Protection, Motor Protection
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC Rating: 100kA @ 480V AC
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal-Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Certification: UL Listed
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679306246
  • GTIN: 00786679306246
