Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker
Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker
Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker
Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker
Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker
Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker

Cutler Hammer FDB3080 - 80A 3-Pole Molded Case Circuit Breaker

Cutler Hammer
Price
Save $909.87
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDB3080 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial electrical systems. It features a thermal-magnetic trip unit with long-time and instantaneous (LI) functions, rated for 80A continuous current and a maximum voltage of 600V AC. The breaker is constructed with a compact F-frame size, measures 3.38" D x 6" H x 4.13" W, weighs 4 lb, and utilizes a three-pole, bolt-on connection for secure installation. It is UL Listed and offers an interrupting capacity of 14kA at 480V, ensuring compliance with safety standards for use in panelboards, switchboards, and industrial control equipment.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 80A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed
  • Applications: Industrial panelboards, switchboards, and motor control centers
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Phase: 3
  • Amperage: 80A
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: F Frame
  • Certification: UL Listed
  • Family: Series C
  • Weight: 4 lb


Product Identification
  • UPC: 786679312537
  • GTIN: 00786679312537
