Cutler Hammer FDB2045 - Molded Case Circuit Breaker, 45A 600V 2-Pole
Cutler Hammer FDB2045 - Molded Case Circuit Breaker, 45A 600V 2-Pole
Cutler Hammer FDB2045 - Molded Case Circuit Breaker, 45A 600V 2-Pole
Cutler Hammer FDB2045 - Molded Case Circuit Breaker, 45A 600V 2-Pole

Cutler Hammer FDB2045 - Molded Case Circuit Breaker, 45A 600V 2-Pole

Cutler Hammer
Price
Save $-558.60
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDB2045 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 45A current rating and a 600V AC voltage rating, housed within a compact F-frame measuring 3.38 in (depth) x 6 in (height) x 2.75 in (width) and weighing 3 lb. The breaker is UL-certified and employs a thermal-magnetic trip mechanism with long-time and instantaneous functions, offering a 14kA interrupting capacity at 600V. Its two-pole, bolt-on configuration and operational temperature range of -25 to 70 °C make it suitable for protecting single-phase branch circuits in panelboards and switchgear.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 45A
  • Dimensions: 3.38 in D x 6 in H x 2.75 in W (85.9 mm x 152.4 mm x 69.9 mm)
  • Weight: 3 lb (1.36 kg)
  • Standards: UL Certified
  • Applications: Industrial Panelboards, Switchgear, Single-Phase Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC Rating: 14kA @ 600V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Breaker Type: Molded Case
  • Family: Series C
  • Item Subcategory: Molded Case


Product Identification
  • UPC: 786679312490
  • GTIN: 00786679312490
