Cutler Hammer FDB2035 - Molded Case Circuit Breaker, 35A, 600V, 2-Pole
Cutler Hammer FDB2035 - Molded Case Circuit Breaker, 35A, 600V, 2-Pole

Cutler Hammer FDB2035 - Molded Case Circuit Breaker, 35A, 600V, 2-Pole

Cutler Hammer
Price
Save $368.37
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FDB2035 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 35A current rating and a 600V AC voltage rating, housed within a compact F-frame measuring 3.38 in (D) x 6 in (H) x 2.75 in (W) and weighing 3 lb. This UL-listed, thermal-magnetic breaker offers both long-time and instantaneous trip functions with a 14kA interrupting capacity at 600V, ensuring compliance with industry safety standards for equipment protection. Its two-pole, bolt-on configuration is engineered for stable performance across an operating temperature range of -25°C to 70°C (-13°F to 158°F), making it suitable for panelboards and switchgear in a variety of demanding environments.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Dimensions: 3.38 in x 6 in x 2.75 in (Depth x Height x Width)
  • Standards: UL Listed
  • Applications: Industrial and Commercial Panelboards, Switchgear
  • Switch Type: Circuit Breaker
  • Configuration: 2-Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Shipping Dimensions: 3.38 in x 6 in x 2.75 in (Depth x Height x Width)
  • Phase: 1
  • Voltage: 600V
  • Amperage: 35A
  • AIC Rating: 14kA @ 600V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Trip Type: Thermal Magnetic
  • Panel Type: Compatible with Standard Panelboards
  • Breaker Type: Molded Case
  • Weight: 3 lb
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679312407
  • GTIN: 00786679312407
