Eaton FD3225 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial power distribution systems. It features a 225A current rating and a 600V AC voltage rating, housed within a compact 3.38" x 6" x 4.13" (LxHxW) frame with a bolt-on connection and load side lugs for secure installation. This thermal magnetic breaker, offering long-time and instantaneous (LI) protection with a 35kA interrupting rating at 480V, is constructed to operate in temperatures from -4°F to 158°F and complies with UL, CSA, and IEC standards. It is typically applied in motor control centers (MCCs), switchboards, and enclosed control panels from manufacturers like Allen-Bradley, Eaton, and Rockwell Automation.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Standard Type, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 225A
  • Frame Size: 225A/F
  • Poles: 3
  • AIC Rating: 35kA @ 480V
  • Phase Connection: 3-Phase, ABC
  • Functions: LI (Long-Time and Instantaneous)
  • Terminal Connection: Load Side Lug
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Weight: 4.5 lb
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679015360
  • GTIN: 00786679015360
