Cutler Hammer FD3060VW - 3-Pole 60A 600V Molded Case Circuit Breaker
Cutler Hammer FD3060VW - 3-Pole 60A 600V Molded Case Circuit Breaker

Cutler Hammer FD3060VW - 3-Pole 60A 600V Molded Case Circuit Breaker

Cutler Hammer
Price
Save $2,576.63
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FD3060VW is a molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It is rated for 600V AC and 60A, providing reliable interruption of fault currents. The breaker measures 3.38 inches in depth, 6 inches in height, and 4.13 inches in width, with a weight of 4.5 lb, constructed with a rugged thermoplastic housing. It complies with UL 489 and CSA standards, ensuring safe operation in commercial and industrial environments. Typical applications include motor control centers, panelboards, and switchboards requiring branch circuit protection.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, non-interchangeable trip unit
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Dimensions: 3.38 in x 6 in x 4.13 in (Depth x Height x Width)
  • Standards: UL 489, CSA
  • Applications: Industrial power distribution, motor control centers, panelboards
  • Switch Type: Toggle
  • Configuration: 3-pole
  • Coil Voltage Maximum: Not applicable (thermal-magnetic)
  • Temp Rating: 40°C ambient
  • Shipping Dimensions: 3.38 in x 6 in x 4.13 in
  • Phase: 3-phase
  • Voltage: 600V AC
  • Amperage: 60A
  • AIC rating: 25 kA at 240V AC, 18 kA at 480V AC, 14 kA at 600V AC
  • Connection: Line and load side lugs
  • Poles: 3
  • Protection: Overcurrent and short-circuit
  • Functions: Circuit isolation and protection
  • Frame Size: FD
  • Trip Type: Thermal-magnetic
  • Panel Type: Industrial panelboard
  • Breaker Type: Molded case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Copper alloy contacts
  • Panel Style: NEMA 1
  • Bus Type: Copper
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Bolt-on
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: 50 hp at 480V AC
  • Aux Contacts: Not included
  • CPT: Not included
  • Full Load Amps: 60A
  • Dist Voltage: 600V AC
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 60A
  • Full Load Amp Minimum: 60A
  • Enclosure: Open style
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper or aluminum
  • Amperage Maximum: 60A
  • Amperage Minimum: 60A
  • Nema Rating: NEMA AB1
  • Switch Style: Toggle
  • Wire Size: 14 AWG to 2 AWG
  • Certification: UL listed, CSA certified
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Pressure lugs
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-phase
  • Standards: UL 489, CSA C22.2 No. 5
  • Compatible Frames: FD series
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: FD
  • Current Rating: 60A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 78667907203
  • GTIN: 00786679072035
