Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)
Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)
Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)
Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)
Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)
Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)

Cutler Hammer FD2090 - 90A Molded Case Circuit Breaker (600V, 2-Pole)

Cutler Hammer
Price
Save $2,342.39
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer FD2090 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial power distribution systems. It features a 90A current rating and a 600V voltage rating, housed within a compact 225A frame with dimensions of 3.38 in (D) x 6 in (H) x 2.75 in (W) and a weight of 3.03 lb. The breaker is CSA Certified, IEC Rated, and UL Listed, ensuring compliance with key industry standards for safety and performance. Its thermal-magnetic protection with long-time and instantaneous (LI) trip functions makes it suitable for use in motor control centers (MCCs), switchboards, and enclosed controls from major manufacturers like Allen-Bradley and Rockwell Automation.

Key Features & Specifications
  • Type: FD Series C, Standard, Molded Case, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 90A
  • Frame Size: 225A/F
  • Poles: 2
  • AIC Rating: 35kA at 480V
  • Connection: Bolt-On, Load Side Lug Terminal
  • Phase: 1 (Phase Connection: AB)
  • Trip Functions: LI - Long-Time and Instantaneous
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Wire Size Range: 14 AWG to 1/0 AWG
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 2.75 in (Width)
  • Weight: 3.03 lb
  • Standards & Certification: CSA Certified, IEC Rated, UL Listed
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse


Product Identification
  • UPC: 786679312292
  • GTIN: 00786679312292
