Westinghouse FD1025 is a molded case circuit breaker designed for providing reliable overcurrent protection in commercial and industrial electrical systems. It features a 25A current rating and a 277V AC voltage rating, housed within a compact F-frame measuring 3.38 in (L) x 6 in (H) x 1.38 in (W) and weighing 2 lb. This UL Listed, thermal-magnetic breaker offers both long-time and instantaneous trip functions, ensuring compliance with industry standards, and its 35kA interrupting rating at 277V makes it suitable for protecting feeders and branch circuits in single-phase applications.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 277V AC
  • Current Rating: 25A
  • Dimensions: 3.38 in x 6 in x 1.38 in (Length x Height x Width)
  • Standards: UL Listed
  • Applications: Commercial & Industrial Feeder/Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Single Pole
  • AIC Rating: 35kA @ 277V
  • Phase: 1
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Certification: UL Listed
  • Family: Series C
  • Country of Origin: Dominican Republic
  • Weight: 2 lb


Product Identification
  • UPC: 786679312124
  • GTIN: 00786679312124
