Eaton FCL3035L - Molded Case Circuit Breaker 35A 480V 3-Pole
Eaton FCL3035L - Molded Case Circuit Breaker 35A 480V 3-Pole

Eaton FCL3035L - Molded Case Circuit Breaker 35A 480V 3-Pole

Cutler Hammer
Price
Save $14,090.52
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Eaton FCL3035L is a 35A, 3-pole molded case circuit breaker from the Current Limit-R family, designed for overcurrent protection in industrial power distribution systems. This thermal-magnetic breaker provides LI (Long-Time and Instantaneous) protection functions at a voltage rating of 480V with a high interrupting capacity of 150kA at 480Vac. The unit features a feed-thru connection, weighs 7.8 lb, and measures 11.2 in x 6 in x 5.7 in (Length/Depth x Height x Width). It is suitable for 3-phase applications requiring reliable short-circuit and overload protection in commercial and industrial environments.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, Current Limit-R Family
  • Voltage Rating: 480V
  • Current Rating: 35A
  • Dimensions: 11.2 in x 6 in x 5.7 in (Length/Depth x Height x Width)
  • Standards: UL, CSA, NEMA
  • Applications: Industrial power distribution, motor protection, feeder circuits
  • Switch Type: Thermal Magnetic
  • Configuration: 3-Pole
  • Coil Voltage Maximum: Not applicable (thermal magnetic)
  • Temp Rating: 40°C
  • Shipping Dimensions: 11.2 in x 6 in x 5.7 in
  • Phase: 3
  • Voltage: 480V
  • Amperage: 35A
  • AIC rating: 150kA@480Vac
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Frame Size: F
  • Trip Type: Thermal Magnetic
  • Panel Type: Industrial
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Copper alloy
  • Panel Style: Standard
  • Bus Type: Feed-Thru
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Panel mount
  • Hz: 50/60
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not included
  • CPT: Not included
  • Full Load Amps: 35A
  • Dist Voltage: 480V
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 35A
  • Full Load Amp Minimum: 35A
  • Enclosure: Open
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper
  • Amperage Maximum: 35A
  • Amperage Minimum: 35A
  • Nema Rating: Not specified
  • Switch Style: Thermal Magnetic
  • Wire Size: 14 AWG to 2 AWG
  • Certification: UL 489, CSA C22.2
  • Circuit Breaker Mounting Style: Panel mount
  • Terminal Connection: Feed-Thru
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Standards: UL, CSA, NEMA
  • Compatible Frames: F frame
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: F
  • Current Rating: 35A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 786679023600
  • GTIN: 00786679000000
