Eaton FAZ-C5/2 is a DIN rail-mounted, two-pole supplementary protector designed for thermal-magnetic circuit protection in single-phase applications up to 480V AC. It features a 5A current rating and a 10kA interrupting capacity, housed in a compact, molded case measuring 1.38 in x 1.38 in x 1.5 in and weighing 0.53 lb. The breaker provides combined long-time and instantaneous (LI) protection and is certified to UL 1077, IEC 60947-2, and CSA C22.2 No. 235 standards for use as equipment protection. Its lug terminals accommodate wire sizes from 18 AWG to 4 AWG, making it suitable for protecting control circuits, industrial machinery, and other electrical equipment.

Key Features & Specifications
  • Type: FAZ Series, Molded Case, Thermal-Magnetic Supplementary Protector
  • Voltage Rating: 480V AC
  • Current Rating: 5A
  • Poles: 2
  • Phase: 1
  • AIC Rating: 10kA @ 277/480V
  • Protection Functions: LI (Long Time and Instantaneous)
  • Connection: DIN Rail Mount with Lug Terminals
  • Wire Size (MCM): 18 AWG to 4 AWG
  • Dimensions: 1.38 in (L) x 1.38 in (H) x 1.5 in (W)
  • Weight: 0.53 lb
  • Standards & Certification: UL 1077, IEC 60947-2, CSA C22.2 No. 235
  • Country of Origin: Romania


Product Identification
  • UPC: 01508278753
  • GTIN: 04015082787530
