Square D FAL36045 - Molded Case Circuit Breaker 45A 600V 3P
Square D FAL36045 - Molded Case Circuit Breaker 45A 600V 3P

Square D FAL36045 - Molded Case Circuit Breaker 45A 600V 3P

Square D
Price
Save $891.10
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D FAL36045 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 45A current rating and a 600V AC voltage rating, housed within a compact F-frame measuring 162.6 mm H x 114.3 mm W x 104.9 mm D and weighing 4.817 lb. The breaker utilizes a thermal-magnetic trip unit for combined long-time and instantaneous (LI) protection, is certified to UL and CSA standards, and is engineered for feed-thru connection in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, FAL Series, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 45A
  • Dimensions: 162.6 mm H x 114.3 mm W x 104.9 mm D (6.4 in x 4.5 in x 4.13 in)
  • Weight: 4.817 lb
  • Standards: UL, CSA Certified
  • Phase: 3
  • Poles: 3
  • AIC Rating: 18kA at 480V AC
  • Connection: Feed-Thru
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: F Frame
  • Wire Size: Accepts #14 AWG to 1/0 AWG copper and #12 AWG to 1/0 AWG aluminum conductors


Product Identification
  • UPC: 785901529750
  • GTIN: 00785901529750
