Square D FAL22030 - Molded Case Circuit Breaker, 30A 2-Pole
Square D FAL22030 - Molded Case Circuit Breaker, 30A 2-Pole

Square D FAL22030 - Molded Case Circuit Breaker, 30A 2-Pole

Square D
Price
Save $525.92
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
Square D FAL22030 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 30A current rating and a 240V AC voltage rating, housed within a compact F-frame design measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 3.12 lb. The breaker utilizes a thermal-magnetic trip unit with long-time and instantaneous (LI) functions and offers a 10kA interrupting capacity at 240V, complying with UL and CSA standards for safety. Its two-pole, feed-thru configuration is commonly applied in panelboards, switchboards, and motor control centers for branch circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, FAL Series
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Dimensions: 6.4 in (162.6 mm) H x 3 in (76.2 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL, CSA Certified
  • Applications: Industrial/Commercial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Frame Size: F Frame
  • Breaker Type: Molded Case
  • Weight: 3.12 lb


Product Identification
  • UPC: 785901254621
  • GTIN: 00785901254621
