Square D FAL22020 - Molded Case Circuit Breaker, 20A 2-Pole (10kA AIC)
Square D FAL22020 - Molded Case Circuit Breaker, 20A 2-Pole (10kA AIC)

Square D FAL22020 - Molded Case Circuit Breaker, 20A 2-Pole (10kA AIC)

Square D
Price
Save $261.56
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
Square D FAL22020 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 20A current rating and a 240V AC voltage rating, housed within a compact F-frame measuring 162.6 mm H x 76.2 mm W x 104.9 mm D and weighing 3 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous (LI) protection, is configured as a 2-pole feed-thru device, and is certified to UL and CSA standards. Its 10kA interrupting rating at 240V makes it suitable for protecting branch circuits and equipment in single-phase applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip, FAL Series
  • Voltage Rating: 240V AC
  • Current Rating: 20A
  • Dimensions: 6.4 in (162.6 mm) H x 3 in (76.2 mm) W x 4.13 in (104.90 mm) D
  • Standards: UL, CSA Certified
  • Applications: Industrial and Commercial Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Feed-Thru
  • Phase: 1
  • AIC Rating: 10kA @ 240V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: F Frame
  • Weight: 3 lb


Product Identification
  • UPC: 785901254614
  • GTIN: 00785901254614
