Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole
Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole

Square D EJB24080 - Molded Case Circuit Breaker 80A 480V 2-Pole

Square D
Price
Save $-791.51
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D EJB24080 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 480V AC voltage rating and an 80A current rating, with a compact physical footprint of 143.76 mm H x 49.78 mm W x 102.87 mm D and a weight of 2.47 lb. The breaker is cULus certified and engineered for operation in temperatures from -25°C to 70°C, ensuring compliance with industry standards for safety and performance. Its thermal-magnetic protection with long-time and instantaneous (LI) trip functions makes it suitable for safeguarding feeders and branch circuits in NF-style panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 80A
  • Dimensions: 5.66 in (143.76 mm) H x 1.96 in (49.78 mm) W x 4.05 in (102.87 mm) D
  • Standards: cULus Certified
  • Applications: Industrial and Commercial Feeder/Branch Circuit Protection in NF Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Poles: 2
  • Phase: 1
  • AIC Rating: 65kA @ 480V
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Panel Type: NF panelboard
  • Breaker Type: Molded Case
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Wire Size: AWG 12 to AWG 2/0 Aluminum, AWG 14 to AWG 2/0 Copper
  • Weight: 2.47 lb
  • Family: EJB Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901650430
  • GTIN: 00785901650430
