Square D EJB14020EPD is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 20A current rating and a 277V voltage rating, housed within a compact, bolt-on unit measuring 168.66 mm H x 49.78 mm W x 102.87 mm D and weighing 2.059 lb. This thermal magnetic breaker provides both long-time and instantaneous trip functions, is cULus certified, and operates effectively across a temperature range of -25 to 70 °C. It is engineered for integration into NF panelboards, offering a 65kA interrupting capacity at 480V to safeguard single-phase circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 277V AC
  • Current Rating: 20A
  • Dimensions: 168.66 mm H x 49.78 mm W x 102.87 mm D (6.64 in x 1.96 in x 4.05 in)
  • Standards: cULus Certified
  • Applications: NF Panelboards, Industrial & Commercial Distribution
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On Connection
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Shipping Dimensions: As per product dimensions
  • Phase: 1
  • Voltage: 277V
  • Amperage: 20A
  • AIC Rating: 65kA @ 480V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: EJB Series
  • Trip Type: Thermal Magnetic
  • Panel Type: NF Panelboard
  • Breaker Type: Molded Case
  • Wire Size: AWG 14 to 6 Copper, AWG 12 to 4 Aluminum
  • Certification: cULus
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Bolt-On
  • Standards: cULus
  • Compatible Frames: NF Panelboard
  • Installation Type: Panel Mount
  • Manufacturer: Schneider Electric
  • Family: EJB Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901484509
  • GTIN: 00785901484509
