The Cutler Hammer EHD3080 is a molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection for three-phase industrial power distribution systems. It features an 80A current rating and a 480V AC voltage rating, housed within a compact 100A frame with dimensions of 3.38" D x 6" H x 4.13" W and a weight of 4.3 lb. This thermal-magnetic breaker, offering Long-Time and Instantaneous (LI) protection functions with a 14kA interrupting rating at 480V, is constructed for bolt-on connection with load side lugs and is certified to UL, CSA, and IEC standards. It is engineered for a wide operating temperature range from -4°F to 158°F and is typically applied in switchboards, motor control centers (MCCs), and enclosed control panels from major manufacturers like Allen-Bradley, Eaton, and Rockwell Automation.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Standard Type
  • Voltage Rating: 480V AC
  • Current Rating: 80A
  • Frame Size: 100A/F
  • Poles: 3
  • AIC Rating: 14kA @ 480V AC
  • Connection: Bolt-On, Load Side Lug Terminals
  • Phase Connection: 3-Phase (ABC)
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Protection: Thermal Magnetic
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Weight: 4.3 lb
  • Wire Size Range: 14 AWG (Min) to 1/0 AWG (Max)
  • Operating Temperature: -4°F to 158°F (-20°C to 70°C)
  • Standards & Certification: UL Listed, CSA Certified, IEC Rated
  • Panel Type: Compatible with Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Breaker Type: Standard
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317594
  • GTIN: 00786679317594
