Cutler Hammer
Price
Save $1,080.68
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer EHD3045 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power systems. It features a 45A current rating and a 480V AC voltage rating for robust electrical performance. The breaker is constructed with a compact F-frame design measuring 3.38" x 6" x 4.13" (LxHxW) and a bolt-on connection for secure installation. It is UL Listed and employs a thermal-magnetic trip mechanism providing both long-time and instantaneous (LI) protection functions with an interrupting capacity of 14kA at 480V. This breaker is suitable for a wide range of industrial applications, including panelboards and switchboards, operating effectively in ambient temperatures from -25°C to 70°C (-13°F to 158°F).

Key Features & Specifications
  • Type: EHD Series C, Molded Case, Thermal Magnetic Circuit Breaker
  • Voltage Rating: 480V AC
  • Current Rating: 45A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed
  • Applications: Industrial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Frame Size: F Frame
  • Certification: UL Listed
  • Weight: 4.3 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317587
  • GTIN: 00786679317587
