Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)
Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)
Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)
Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)
Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)
Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)

Cutler Hammer EHD3010 - Molded Case Circuit Breaker (10A, 480V, 3-Pole)

Cutler Hammer
Price
Save $751.81
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer EHD3010 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power systems. It features a 10A thermal-magnetic trip unit with long-time and instantaneous functions, rated for 480V AC systems with an interrupting capacity of 14kA. The compact, bolt-on, 3-pole breaker is constructed in an F-frame size measuring 3.38" x 6" x 4.13" (LxHxW) and weighs 4.1 lb, operating reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). This UL-listed device complies with industry standards and is engineered for integration into panelboards and switchboards within commercial and industrial facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 10A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: UL Listed
  • Applications: Industrial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 3
  • AIC rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Weight: 4.1 lb
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317037
  • GTIN: 00786679317037
