Cutler Hammer EHD2070 - 70A Molded Case Breaker (480V, 14kA)
Cutler Hammer EHD2070 - 70A Molded Case Breaker (480V, 14kA)
Cutler Hammer EHD2070 - 70A Molded Case Breaker (480V, 14kA)
Cutler Hammer EHD2070 - 70A Molded Case Breaker (480V, 14kA)

Cutler Hammer EHD2070 - 70A Molded Case Breaker (480V, 14kA)

Cutler Hammer
Price
Save $1,328.92
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer EHD2070 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial electrical systems. It features a 70A current rating and a 480V voltage rating, housed within a compact 100A frame with dimensions of 3.38" x 6" x 2.75" (L x H x W) and a weight of 3 lb. This thermal magnetic breaker is CSA Certified, IEC Rated, and UL Listed, ensuring compliance with key industry standards for safety and performance. Its 2-pole, bolt-on configuration with load side lug terminals and a 14kA interrupting rating at 480V makes it suitable for integration into motor control centers, switchboards, and enclosed controls from major manufacturers like Allen-Bradley and Eaton.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Series C Family, EHD Type
  • Voltage Rating: 480V AC
  • Current Rating: 70A
  • Frame Size: 100A/F
  • Poles: 2
  • Connection: Bolt-On
  • AIC Rating: 14kA @ 480V
  • Phase: 1
  • Phase Connection: ABC
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Terminal Connection: Load Side Lug
  • Wire Size Range: 14 AWG (Min) to 1/0 AWG (Max)
  • Dimensions: 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
  • Weight: 3 lb
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: CSA Certified, IEC Rated, UL Listed
  • Panel Compatibility: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317495
  • GTIN: 00786679317495
