Cutler Hammer EHD1080 - Molded Case Breaker 80A 277V (14kA AIC)
Cutler Hammer EHD1080 - Molded Case Breaker 80A 277V (14kA AIC)

Cutler Hammer EHD1080 - Molded Case Breaker 80A 277V (14kA AIC)

Cutler Hammer
Price
Save $491.01
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer EHD1080 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a thermal-magnetic trip mechanism with long-time and instantaneous functions, rated for 80A at 277V AC in a single-pole, bolt-on configuration. The compact F-frame unit measures 3.38" x 6" x 1.38" (LxHxW) and is constructed for operation in temperatures from -25°C to 70°C (-13°F to 158°F). This UL-listed breaker complies with industry standards and offers an interrupting capacity of 14kA at 480V, making it suitable for panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Series C, EHD Type
  • Voltage Rating: 277V AC
  • Current Rating: 80A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 1.38 in (Width)
  • Standards: UL Listed
  • Applications: Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 14kA @ 480V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: F Frame
  • Breaker Type: Molded Case
  • Country of Origin: Dominican Republic
  • Weight: 2 lb


Product Identification
  • UPC: 786679317549
  • GTIN: 00786679317549
