Eaton EHD1030 - Molded Case Circuit Breaker 30A 277V (1-Pole)
Eaton EHD1030 - Molded Case Circuit Breaker 30A 277V (1-Pole)

Eaton EHD1030 - Molded Case Circuit Breaker 30A 277V (1-Pole)

Eaton
Price
Save $189.25
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Eaton EHD1030 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 30A current rating and a 277V voltage rating, housed within a compact 100A frame with dimensions of 3.38 in (D) x 6 in (H) x 1.38 in (W) and a weight of 1.6 lb. This thermal magnetic breaker is CSA Certified, IEC Rated, and UL Listed, ensuring compliance with key industry standards for safety and performance. Its single-pole, bolt-on configuration with load side lug terminals makes it suitable for integration into various panel types including Allen Bradley MCCs, Eaton MCCs, switchboards, and enclosed controls.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Series C Family, EHD Type, Standard Breaker Type
  • Voltage Rating: 277V
  • Current Rating: 30A
  • Frame Size: 100A/F
  • AIC Rating: 14kA @ 480V
  • Poles: 1
  • Phase: 1
  • Phase Connection: A
  • Connection: Bolt-On
  • Terminal Connection: Load Side Lug
  • Functions: LI - Long-Time and Instantaneous Trip
  • Protection: Thermal Magnetic
  • Panel Type: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Standards: CSA Certified, IEC Rated, UL Listed
  • Certification: CSA Certified, IEC Rated, UL Listed
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Dimensions: 3.38 in x 6 in x 1.38 in (Depth x Height x Width)
  • Weight: 1.6 lb
  • MCM Size: Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317341
  • GTIN: 00786679317341
