The Cutler Hammer EHD1015 is a molded case circuit breaker designed to provide reliable overcurrent protection for industrial electrical circuits. It features a 15A current rating and a 277V AC voltage rating, housed within a compact 100A frame with bolt-on connections and load side lug terminals measuring 3.38 in (L) x 6 in (H) x 1.38 in (W) and weighing 1.45 lb. This thermal magnetic breaker is CSA Certified, IEC Rated, and UL Listed, ensuring compliance with key industry standards for safety and performance. Its single-pole, standard configuration with a 14kA interrupting rating at 480V makes it suitable for integration into Allen Bradley MCCs, Eaton MCCs, switchboards, and other enclosed control panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, LI (Long-Time and Instantaneous) Trip
  • Voltage Rating: 277V AC
  • Current Rating: 15A
  • Frame Size: 100A/F
  • Poles: 1
  • Connection: Bolt-On
  • AIC Rating: 14kA @ 480V
  • Phase: Single (Phase Connection A)
  • Terminal Connection: Load Side Lug
  • Wire Size Range (MCM): 14 AWG (Min) to 1/0 AWG (Max)
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
  • Weight: 1.45 lb
  • Standards & Certification: CSA Certified, IEC Rated, UL Listed
  • Compatible Panel Types: Allen Bradley MCC, Eaton MCC, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
  • Family: Series C
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679317310
  • GTIN: 00786679317310
