Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P
Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P
Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P
Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P
Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P
Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P

Cutler Hammer EGS3100FFG - Molded Case Circuit Breaker, 100A 600V 3P

Eaton
Price
Save $751.66
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer EGS3100FFG is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 100A current rating and a 600V AC voltage rating, housed in a compact, feed-thru configured unit measuring 2.99" x 5.5" x 3" (LxHxW) and weighing 2.9 lb. The breaker is certified to UL, IEC, CSA, and CE standards and operates across a temperature range of -25°C to 70°C (-13°F to 158°F). Its thermal-magnetic protection with long-time and instantaneous trip functions and a 35kA interrupting rating at 480V AC makes it suitable for protecting feeders and branch circuits in panelboards and switchgear.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Feed-Thru Connection
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 2.99 in (Depth) x 5.5 in (Height) x 3 in (Width)
  • Standards: UL Listed, IEC Rated, CSA Certified, CE Marked
  • Applications: Industrial Power Distribution, Panelboards, Switchgear
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC rating: 35kA @ 480V AC
  • Connection: Feed-Thru
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 2.9 lb
  • Family: Series G
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782114877227
  • GTIN: 00782114877227
