Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P
Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P
Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P
Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P
Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P
Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P

Cutler Hammer EGS3015FFG - Molded Case Circuit Breaker 15A 600V 3P

Cutler Hammer
Price
Save $775.74
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer EGS3015FFG is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial power distribution systems. It features a 15A current rating and a 600V AC voltage rating, housed in a compact, feed-thru connection design measuring 2.99" x 5.5" x 3" (LxHxW) and weighing 3 lb. The breaker is certified to IEC, UL, CSA, and CE standards and offers a 35kA interrupting capacity at 480V, with an operational temperature range of -25 to 70 °C. Its thermal-magnetic protection with long-time and instantaneous trip functions makes it suitable for safeguarding motors, feeders, and branch circuits in commercial and industrial panels.

Key Features & Specifications
  • Type: EGS Series G, Molded Case, Thermal Magnetic Protection with Long-Time & Instantaneous Trip
  • Voltage Rating: 600V AC
  • Current Rating: 15A
  • Dimensions: 2.99 in (Depth) x 5.5 in (Height) x 3 in (Width)
  • Standards: IEC Rated, UL Listed, CSA Certified, CE Marked
  • Applications: Industrial power distribution, motor protection, panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • AIC Rating: 35kA @ 480V AC
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Weight: 3 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782116131129
  • GTIN: 00782116131129
