Cutler Hammer EGS2040FFG - 40A 2-Pole 600V Molded Case
Cutler Hammer EGS2040FFG - 40A 2-Pole 600V Molded Case

Cutler Hammer EGS2040FFG - 40A 2-Pole 600V Molded Case

Cutler Hammer
Price
Save $192.41
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer EGS2040FFG Circuit Breaker - 40A 2-Pole 600V Molded Case The Cutler Hammer EGS2040FFG is a 2-pole molded case circuit breaker from the Series G family, designed to provide overcurrent protection through long-time and instantaneous trip functions. It is rated for 40A at 600V AC and offers a high interrupting capacity of 35kA at 480V, ensuring reliable fault interruption in industrial power systems. This thermal-magnetic breaker features a feed-thru connection, measures 2.99 inches in depth by 5.5 inches in height by 2 inches in width, and weighs 1.9 lb, with an operating temperature range of -13 to 158 °F (-25 to 70 °C). It complies with industry standards for molded case circuit breakers and is suitable for single-phase applications in commercial and industrial distribution panels. Typical applications include branch circuit protection in motor control centers, lighting panels, and switchboards where compact, high-ampacity protection is required.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic
  • Voltage Rating: 600V AC
  • Current Rating: 40A
  • Dimensions: 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
  • Standards: Industry standard molded case circuit breaker compliance
  • Applications: Industrial distribution panels, motor control centers, lighting panels
  • Switch Type: Circuit breaker
  • Configuration: 2-pole
  • Coil Voltage Maximum: Not applicable (thermal magnetic)
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Shipping Dimensions: 2.99 in x 5.5 in x 2 in
  • Phase: 1
  • Voltage: 600V
  • Amperage: 40A
  • AIC rating: 35kA@480V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Frame Size: EGS
  • Trip Type: Thermal Magnetic
  • Panel Type: Not specified
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not specified
  • Class Rating: Not specified
  • Diameter: Not specified
  • Velocity: Not specified
  • Clip Center: Not specified
  • Clas: Not specified
  • Mounting: Not specified
  • Hz: 50/60 Hz (typical)
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: 40A
  • Dist Voltage: Not specified
  • Bucket Size: Not specified
  • Bucket Style: Not specified
  • Bucket Type: Not specified
  • Full Load Amp Maximum: 40A
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 40A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Circuit breaker
  • Wire Size: Not specified
  • Certification: UL listed (typical)
  • Circuit Breaker Mounting Style: Panel mount
  • Terminal Connection: Feed-thru
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-phase
  • Standards: UL 489, CSA C22.2 (typical)
  • Compatible Frames: Series G
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: EGS
  • Current Rating: 40A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 078668501883
  • GTIN: 00786685018836
