Cutler Hammer
Price
Save $198.46
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Cutler Hammer EGB3100FFB is a molded case circuit breaker designed to provide reliable overcurrent and short-circuit protection for three-phase industrial electrical systems. It features a 100A current rating and a 480V AC voltage rating, housed within a compact, bolt-on configuration measuring 2.99" x 5.5" x 3" (LxHxW) and weighing 2.91 lb. This thermal-magnetic trip unit offers both long-time and instantaneous trip functions, is rated for an interrupting capacity of 18kA at 480V, and operates within a temperature range of -25 to 70 °C. Compliant with UL, CSA, IEC, and CE standards, it is engineered for integration into panelboards, switchboards, and industrial control equipment requiring robust circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 100A
  • Dimensions: 2.99 in (Depth) x 5.5 in (Height) x 3 in (Width)
  • Standards: UL Listed, CSA Certified, IEC Rated, CE Marked
  • Applications: Industrial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • AIC Rating: 18kA @ 480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Frame Size: Series G
  • Trip Type: Thermal Magnetic
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Weight: 2.91 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786685381664
  • GTIN: 00786685381664
