Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole
Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole

Square D EGB24125 - Molded Case Circuit Breaker 125A 480V 2-Pole

Square D
Price
Save $1,584.67
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D EGB24125 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 125A current rating and a 480V AC voltage rating, housed within a compact, bolt-on unit measuring 143.76 mm H x 49.78 mm W x 102.87 mm D and weighing 2.458 lb. The breaker is cULus certified and employs a thermal-magnetic trip mechanism with long-time and instantaneous (LI) functions for coordinated protection. Its 35kA interrupting rating at 480V and compatibility with NF panelboards make it suitable for protecting feeders and branch circuits in commercial and industrial facilities.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 480V AC
  • Current Rating: 125A
  • Dimensions: 5.66 in (143.76 mm) H x 1.96 in (49.78 mm) W x 4.05 in (102.87 mm) D
  • Standards: cULus Certified
  • Applications: Feeder and Branch Circuit Protection in NF Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Temp Rating: 104 °F (40 °C)
  • Shipping Dimensions: 5.66 in x 1.96 in x 4.05 in
  • Phase: 1
  • Voltage: 480V
  • Amperage: 125A
  • AIC rating: 35kA @ 480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous)
  • Frame Size: EGB
  • Trip Type: Thermal Magnetic
  • Panel Type: NF panelboard
  • Breaker Type: Molded Case
  • Wire Size: AWG 12 to 2/0 Aluminum; AWG 14 to 2/0 Copper
  • Certification: cULus
  • Family: EGB Series
  • Country of Origin: Mexico
  • Weight: 2.458 lb


Product Identification
  • UPC: 785901128618
  • GTIN: 00785901128618
