The Square D EGB24050SA is a 2-pole molded case circuit breaker from Schneider Electric's EGB Series, designed to provide overcurrent protection through long-time and instantaneous trip functions. It is rated for 50A at 480V AC with a 35kA interrupting capacity, operating on a single-phase system with a thermal magnetic protection mechanism. This bolt-on breaker measures 5.66 x 2.94 x 4.05 inches (H x W x D), weighs 3.06 lb, and accommodates wire sizes from AWG 12 to AWG 2/0 for aluminum and AWG 14 to AWG 2/0 for copper. It is certified to industry standards and operates within a temperature range of -13°F to 158°F (-25°C to 70°C), making it suitable for industrial applications requiring reliable circuit protection in distribution panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Dimensions: 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Standards: Industry certified
  • Applications: Industrial circuit protection in distribution panels
  • Poles: 2
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • AIC rating: 35kA@480V
  • Phase: 1
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Wire Size: AWG 12 to AWG 2/0 (Aluminum), AWG 14 to AWG 2/0 (Copper)
  • Weight: 3.06 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 3606486143490
