Square D EGB24030SA - Molded Case Circuit Breaker 30A 480V
Square D EGB24030SA - Molded Case Circuit Breaker 30A 480V

Square D EGB24030SA - Molded Case Circuit Breaker 30A 480V

Square D
Price
Save $659.15
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D EGB24030SA is a 2-pole molded case circuit breaker designed for overcurrent protection in industrial power distribution systems. It provides a 30A current rating with a 480V voltage rating and a 35kA interrupting capacity at 480V, utilizing a thermal magnetic trip mechanism for long-time and instantaneous fault protection. The bolt-on unit measures 5.66 inches in height, 2.94 inches in width, and 4.05 inches in depth, weighing 3.06 lb, and accepts copper wire from AWG 14 to AWG 6 or aluminum wire from AWG 12 to AWG 6. This breaker is part of the EGB Series from Schneider Electric, manufactured in Mexico, and operates within a temperature range of -13°F to 158°F (-25°C to 70°C) for single-phase applications. It is commonly used in panelboards and switchboards for commercial and light industrial settings requiring reliable branch circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 480V
  • Current Rating: 30A
  • Dimensions: 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Standards: UL Listed, CSA Certified
  • Applications: Branch circuit protection in panelboards and switchboards
  • Switch Type: Thermal Magnetic
  • Configuration: 2-Pole
  • Coil Voltage Maximum: Not applicable
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: 5.66 in x 2.94 in x 4.05 in
  • Phase: 1
  • Voltage: 480V
  • Amperage: 30A
  • AIC rating: 35kA@480V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Frame Size: EGB
  • Trip Type: Thermal Magnetic
  • Panel Type: Not specified
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Bolt-On
  • Hz: 50/60 Hz
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper or Aluminum
  • Amperage Maximum: 30A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Not applicable
  • Wire Size: AWG 12 to AWG 6, Aluminum; AWG 14 to AWG 6, Copper
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Bolt-On
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single Phase
  • Standards: UL 489, CSA C22.2 No. 5
  • Compatible Frames: EGB Series
  • Installation Type: Fixed
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: EGB
  • Current Rating: 30A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 3606486143469
