Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole
Square D EGB24025 - Molded Case 25A 480V 2-Pole

Square D EGB24025 - Molded Case 25A 480V 2-Pole

Square D
Price
Save $526.75
/
Condition
  • Low stock - 8 items left
  • Backordered, shipping soon
Call for Price
Square D EGB24025 is a 2-pole molded case circuit breaker from the EGB Series, designed for thermal-magnetic overcurrent protection in NF panelboards. It is rated for 480V AC, 25A, and 35kA interrupting capacity at 480V, with a single-phase configuration. The breaker measures 5.66 in x 1.96 in x 4.05 in, weighs 2.47 lb, and features a bolt-on connection accepting AWG 12 to AWG 6 aluminum or AWG 14 to AWG 6 copper wire. It is cULus certified and operates within a temperature range of -13°F to 158°F (-25°C to 70°C). This unit is suitable for industrial applications requiring LI (Long-Time and Instantaneous) trip functions.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic
  • Voltage Rating: 480V AC
  • Current Rating: 25A
  • Dimensions: 5.66 in x 1.96 in x 4.05 in (143.76 mm x 49.78 mm x 102.87 mm)
  • Standards: cULus
  • Applications: Industrial panelboard protection
  • Poles: 2
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: EGB
  • Trip Type: Thermal Magnetic
  • Panel Type: NF panelboard
  • Breaker Type: Molded Case
  • Phase: 1
  • AIC rating: 35kA@480V
  • Wire Size: AWG 12 to AWG 6, Aluminum, AWG 14 to AWG 6, Copper
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Weight: 2.47 lb
  • Manufacturer: Schneider Electric
  • Family: EGB Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901130291
  • GTIN: 00785901130291
