Cutler Hammer EGB2050FFG - Molded Case Circuit Breaker, 50A 2-Pole

Price
Regular price $612.87
Regular price $1,029.18 Sale price $612.87
Save $416.31
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
The Cutler Hammer EGB2050FFG is a molded case circuit breaker designed to provide reliable thermal-magnetic protection for 50A, single-phase circuits in industrial and commercial applications. It features a 480V AC voltage rating and an interrupting capacity of 18kA at 480V, housed in a compact, feed-thru connection design measuring 2.99" x 5.5" x 2" (LxHxW) and weighing 2 lb. This Series G breaker is certified to UL, CSA, IEC, and CE standards for global compliance and operates effectively across a temperature range of -25°C to 70°C (-13°F to 158°F), making it suitable for panelboards, switchboards, and industrial control panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection with Long Time and Instantaneous Trip Functions
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Dimensions: 2.99 in (Depth) x 5.5 in (Height) x 2 in (Width)
  • Standards: UL Listed, CSA Certified, IEC Rated, CE Marked
  • Applications: Industrial and Commercial Panelboards, Switchboards, Control Panels
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 1
  • AIC Rating: 18kA @ 480V
  • Connection: Feed-Thru
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: Series G
  • Trip Type: Thermal Magnetic
  • Breaker Type: Molded Case
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 2 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786685018492
  • GTIN: 00786685018492
