Cutler Hammer EDB3200 - Molded Case Circuit Breaker, 200A 3P (22kA AIC)
Cutler Hammer EDB3200 - Molded Case Circuit Breaker, 200A 3P (22kA AIC)

Cutler Hammer EDB3200 - Molded Case Circuit Breaker, 200A 3P (22kA AIC)

Cutler Hammer
Price
Save $918.59
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Cutler Hammer EDB3200 is a molded case circuit breaker designed for providing reliable overcurrent protection in three-phase industrial electrical systems. It features a 200A current rating and a 240V AC voltage rating, housed within a compact F-frame measuring 3.38 in (D) x 6 in (H) x 4.13 in (W) and weighing 3 lb. The breaker is certified to cULus and IEC standards, utilizing a thermal-magnetic trip unit with long-time and instantaneous functions for coordinated protection. Its 22kA interrupting rating at 240V and bolt-on lug connection make it suitable for panelboards, switchboards, and industrial control panels requiring robust circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, EDB Series C
  • Voltage Rating: 240V AC
  • Current Rating: 200A
  • Dimensions: 3.38 in (Depth) x 6 in (Height) x 4.13 in (Width)
  • Standards: cULus, IEC
  • Applications: Industrial Panelboards, Switchboards, Motor Control Centers
  • Switch Type: Circuit Breaker
  • Configuration: Three-Pole
  • Temp Rating: 104 °F (40 °C)
  • Phase: 3
  • AIC Rating: 22kA @ 240V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous
  • Frame Size: F Frame
  • Terminal Connection: Lug
  • Certification: cULus, IEC
  • Country of Origin: Mexico
  • Weight: 3 lb


Product Identification
  • UPC: 782116152742
  • GTIN: 00782116152742
