Cutler-Hammer EDB3150 - 35A 3-Pole Molded Case Circuit Breaker
Cutler-Hammer EDB3150 - 35A 3-Pole Molded Case Circuit Breaker

Cutler-Hammer EDB3150 - 35A 3-Pole Molded Case Circuit Breaker

Cutler Hammer
Price
Save $1,326.29
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
The Cutler-Hammer EDB3150 is a molded case circuit breaker designed to provide reliable overcurrent protection for three-phase industrial electrical systems. It features a 35A current rating and a 240V AC voltage rating, housed within a compact F-frame measuring 3.38" x 6" x 4.13" (LxHxW) and weighing 3 lb. This thermal-magnetic trip unit provides both long-time and instantaneous (LI) protection functions, is certified to cULus and IEC standards, and is suitable for applications requiring a 22kA interrupting capacity at 240V. Its bolt-on lug connection accommodates wire sizes from 4 to 4/0 AWG and is rated for operation in ambient temperatures up to 40°C (104°F).

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Trip, Series C
  • Voltage Rating: 240V AC
  • Current Rating: 35A
  • Frame Size: F Frame
  • Poles: 3
  • Connection: Bolt-On, Lug Terminal
  • Wire Size: 4 to 4/0 AWG
  • AIC Rating: 22kA @ 240V
  • Phase: 3
  • Functions: Long-Time and Instantaneous (LI) Protection
  • Standards/Certification: cULus, IEC
  • Dimensions: 3.38 in (D) x 6 in (H) x 4.13 in (W)
  • Weight: 3 lb
  • Temp Rating: 40°C (104°F)
  • Country of Origin: Mexico


Product Identification
  • UPC: 782116152780
  • GTIN: 00782116152780
