Siemens ED63A100 - Molded Case Circuit Breaker, 100A, 600V AC
Siemens ED63A100 - Molded Case Circuit Breaker, 100A, 600V AC

Siemens ED63A100 - Molded Case Circuit Breaker, 100A, 600V AC

Siemens
Price
Save $3,591.63
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED63A100 is a molded case circuit breaker from the Sentron Series designed to provide instantaneous magnetic-only protection for three-phase industrial power distribution systems. It features a 100A current rating and a 600V AC voltage rating, housed within a compact ED frame with bolt-on connections and dimensions of 6.693" x 5.906" x 3.969" (170mm x 150mm x 101mm). The breaker is IEC certified and UL listed, with an interrupting capacity of 25kA at 480V, and operates reliably across a temperature range of -25°C to 70°C. Its design supports copper or aluminum conductors from AWG 10 to 1/0, making it suitable for panelboards, switchboards, and industrial control panels requiring reliable short-circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Magnetic-Only Protection, Instantaneous Trip
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 6.693" H x 5.906" W x 3.969" D (170mm x 150mm x 101mm)
  • Weight: 3.889 lb
  • Standards: IEC Certified, UL Listed
  • Applications: Industrial power distribution, panelboards, switchboards, control panels
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 3
  • Poles: 3
  • Connection: Bolt-On
  • Protection: Magnetic Only
  • Functions: Instantaneous Trip
  • Frame Size: ED Frame
  • Trip Type: Magnetic
  • AIC Rating: 25kA @ 480V AC
  • Wire Size: AWG 10 to AWG 1/0 (Copper or Aluminum)
  • Temp Rating: -25°C to +70°C (-13°F to 158°F)
  • Certification: IEC, UL
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643210868
  • GTIN: 00783643210868
