Siemens ED61B050 - Molded Case Circuit Breaker 50A 600VAC
Siemens ED61B050 - Molded Case Circuit Breaker 50A 600VAC

Siemens ED61B050 - Molded Case Circuit Breaker 50A 600VAC

Siemens
Price
Save $761.18
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens ED61B050 is a molded case circuit breaker designed for providing reliable overcurrent protection in industrial and commercial electrical systems. It features a 50A current rating and a 600V AC voltage rating, housed within a compact ED frame measuring 0.787" x 4.724" x 5.924" and weighing 1.239 lb. The breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, is certified to UL and IEC standards, and operates effectively across a temperature range of -25°C to 70°C. Its single-pole, bolt-on design with a 30kA interrupting capacity at 347V makes it suitable for protecting branch circuits and equipment in panelboards and switchboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 50A
  • Dimensions: 0.787" W x 4.724" H x 5.924" D (20mm x 120mm x 150.5mm)
  • Standards: UL Listed, IEC Certified
  • Applications: Industrial & Commercial Panelboards, Switchboards, Branch Circuit Protection
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to +70°C
  • Phase: 1
  • AIC rating: 30kA @ 347V
  • Connection: Bolt-On
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: ED Frame
  • Wire Size: 10 to 4 AWG (Copper/Aluminum)
  • Certification: IEC Certified, UL Listed
  • Weight: 1.239 lb


Product Identification
  • UPC: 783643218512
  • GTIN: 00783643218512
