Siemens ED43B015 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 15A current rating and a 480V AC voltage rating, housed within a compact, durable frame measuring 6.693" x 5.906" x 3.938" and weighing 3.715 lb. This thermal-magnetic breaker is HACR rated and UL Listed, ensuring compliance with industry safety standards for use in SB switchboards and Sentron panelboards within industrial and commercial facilities.
Key Features & Specifications
Type: Molded Case Circuit Breaker, Thermal Magnetic Protection with Long Time and Instantaneous Trip Functions
Voltage Rating: 480V AC
Current Rating: 15A
Frame Size: 125A/ED
AIC Rating: 18kA at 480V
Poles: 3
Phase Connection: ABC
Connection: Lug In Panelboard, Load Side Lug Terminals
