Siemens ED42S125A - Molded Case Breaker 125A 480V AC (Non-Automatic)
Siemens ED42S125A - Molded Case Breaker 125A 480V AC (Non-Automatic)

Siemens ED42S125A - Molded Case Breaker 125A 480V AC (Non-Automatic)

Siemens
Price
Save $2,159.79
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Siemens ED42S125A is a molded case circuit breaker from the Sentron Series designed for providing a non-automatic disconnect function in industrial power distribution systems, featuring no overcurrent protection. It is rated for 125A at 480V AC in a single-phase configuration and offers an interrupting capacity of 18kA at 240V AC. The compact, bolt-on unit measures 6.693" x 5.906" x 2.793" (170mm x 150mm x 71mm), weighs 2.599 lb, and is constructed within a durable ED frame for reliable operation in temperatures from -25°C to 70°C. This breaker is IEC certified and UL listed, ensuring compliance with international safety and performance standards for integration into panelboards and switchgear.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Non-Automatic (Disconnect Only), ED Frame
  • Voltage Rating: 480V AC
  • Current Rating: 125A
  • Dimensions: 6.693 in x 5.906 in x 2.793 in (170 mm x 150 mm x 71 mm)
  • Standards: IEC Certified, UL Listed
  • Applications: Industrial power distribution, panelboard and switchgear integration
  • Switch Type: Circuit Breaker
  • Configuration: Fixed
  • Phase: 1
  • AIC Rating: 18kA @ 240V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Non-Automatic (Disconnect Function Only)
  • Functions: NA - No Overcurrent Protection
  • Frame Size: ED Frame
  • Trip Type: Non-Automatic
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Weight: 2.599 lb
  • Certification: IEC Certified, UL Listed
  • Circuit Breaker Mounting Style: Fixed
  • Terminal Connection: Bolt-On (Lugs Not Included)
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643216532
  • GTIN: 00783643216532
